เครื่องบันทึก DVR 8 ช่อง 5 ระบบ DVR 5-in-1 (AHD, CVI, TVI, CVBS, IPC), H.265 high profile (8+4=12CH) Resolution AHD/TVI: 5MP lite, 4MP lite, 2MP, 2MP lite, 720P, 960H, WD1 Resolution CVI: 4MP, 3MP, 1080P, 720P,WD1 Recording AHD:1280x1936@10fps.,AHD/CVI/TVI: 1920x1080P@12fps, AHD/CVI/TVI:1280x720@25fps.,CVBS: 960x576@25fps TVI: 1280x1936@10fps., CVI:1280x1440@12fps +IPC x4 (Max.5MP@30fps) BNCx8, HDMIx1, VGAx1, CVBSx1, Audio in x8, Audio out x1, Alarm in x4, Alarm out x2, RJ45x1, USBx2 HDD x1 (Max. 10Tb.), e-SATA x1 Bandwidth 36/40 Mbps(access/transfer) N9000 menu,Cloud P2P (QRCODE), POS, intelligent smart playback Power Suppply DC12V/2000mA

เครื่องบันทึก DVR 4 ช่อง 5 ระบบ DVR 5-in-1 (AHD, CVI, TVI, CVBS, IPC) H.265 high profile (4+2=6CH) Resolution AHD/TVI: 5MP lite, 4MP lite, 2MP, 2MP lite, 720P, 960H, WD1 Resolution CVI: 4MP, 3MP, 1080P, 720P,WD1 Recording 5MP lite 1280x1936@10fps x4, 4MP lite 1280x1440@12fps x4, 1080P@12fps x4 1080P lite,720P/WD1@25fps x4, analog 960x576@25fps x4 + IPC x2 (Max.5MP@25fps) BNCx4, HDMIx1, VGAx1, CVBSx1, Audio in x4, Audio out x1, Alarm in x4, Alarm out x1, RJ45x1, USBx2, HDD x1 (Max. 10Tb.) Bandwidth 36/40 Mbps(access/transfer) N9000 menu,Cloud P2P (QRCODE), POS, intelligent smart playback Power Suppply DC12V/2000mA

เครื่องบันทึก DVR 16 ช่อง 5 ระบบ 16 CH TVI / AHD/CVI 16 CH DVR support 2CH 5MP / 4MP / 1080P / 960P /720P H.265+/H.265/H.264 coding Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse Multi-mode recording: manual / timed / motion / Al recording Playback : 16 CH simultaneously playback Search: time slice, time, event, tag search Express and flexible backup via USB, network and so on Pentaplex: preview, record, playback, backup and remote access DHCP, DDNS, PPPoE network protocol Remote control via Web or CMS : preview, playback, backup, PTZ and configuration Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device Authorization management, log review and device status review Support 1080P output, true high resolution display Support PTZ preset and auto cruise, up to 255 presets and 8 cruises Support NAT function and QRCode scanning by mobile phones Powerful mobile surveillance by smart phones with iOS and Andriod OS

เครื่องบันทึก DVR 5 ระบบ สำหรับ 8 ช่อง 8CH DVR supports CH 1080P / 960P /720P IP video input Adopt standard H.265 high profile compression format to gethigh-quality video at much lower bit rate Intuitive and user-friendly Graphics User Interface (GUI), window style operation by mouse Multi-mode recording: manual / timed / motion / Al recording Playback : 8CH simultaneously playback Search: time slice, time, event, tag search Express and flexible backup via USB, network and so on Pentaplex: preview, record, playback. backup and remote access DHCP, DDNS, PPPoE network protocol Remote control via Web or CMS : preview, playback, backup, PTZ and configuration Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device Authorization management, log review and device status review Supports 1080P output, true high resolution display Supports PTZ preset and auto cruise, up to 255 presets and 8 cruises Supports NAT function and QRCode scanning by mobile phones Powerful mobile surveillance by smart phones with iOS and Andriod OS

เครื่องบันทึกภาพ DVR 5 ระบบ สำหรับ 4 ช่อง 4CH DVR supports CH 1080P / 960P /720P IP video input Adopt standard H.265 high profile compression format to get high-quality video at much lower bit rate Intuitive and user-friendly Graphics User Interface (GUI), window style operation by mouse Multi-mode recording: manual / timed / motion / Al recording Playback : 4CH simultaneously playback Search: time slice, time, event, tag search Express and flexible backup via USB, network and so on Pentaplex: preview, record, playback. backup and remote access DHCP, DDNS, PPPoE network protocol Remote control via Web or CMS : preview, playback, backup, PTZ and configuration Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device Authorization management, log review and device status review Supports 1080P output, true high resolution display Supports PTZ preset and auto cruise, up to 255 presets and 8 cruises Supports NAT function and QRCode scanning by mobile phones Powerful mobile surveillance by smart phones with iOS and Andriod OS
